ASD Seagoing tugboat

4.000 bhp, 60 mt bollard pull

download leaflet



Main Characteristics

Length:31,12 m
Beam:10.32 m
Draft:abt. 4.50 – max 5.00 m
Speed:up to 13,5 kn
Classification:

BV I HULL + MACH Tug FIFI 1 – Waterspraying

Unrestricted Navigation AUT-UMS

ITC ’69358 GT / 107 NT
Flag:The Netherlands
Homeport:Dordrecht
Call Sign:P C P P
IMO no.:9264386
Built:2002
Yard:Astilleros Armon Vigo S.A.
Fuel Capacity:abt. 273 m³



Deck Equipment

  • Waterfall Towing winch aft, Main towing wire 800m ø44mm

    Second towing wire 600m ø44mm

  • Escort / Port winch fwd, Rope ø 80mm, 100m length
  • Deckcrane, Palfinger 6.5T at 1,00m > 1T at 10,70m
  • Free deck area 64m2



Engine Room

  • Two Diesel engines, Caterpillar 3516 B TA HD/B, 1498 kW at 1800 rpm each
  • Two Auxiliary engines, Caterpillar 3304 BT 100 kVa each
  • One bowthrusther auxiliary engine, Caterpillar 3406
  • FiFi pump, 2700m3/hr



Propulsion

  • Two Azimuth Stern Drive Propulsion units, make Schottel SRP1212
  • Two fixed pitch propellors, 2300mm diameter each
  • One bowthruster, 250bhp, make Schottel ST110LK



General

  • The tug is fully equipped for the offshore rigmoves, seagoing towage,

    Harbour assistance and salvage operations.

  • The tug is FiFi classed, FIFI 1 + Waterspraying
  • The Fifi monitors are having a throughput and throwing capacity of 2700 m3/hr.



    The tug itself has a deluge protection system by waterspraying all around the hull.

  • Onboard the tug is fitted with two dispersant oil recovery booms.
  • The EN AVANT 10 can spray besides water also foam, bulk capacity of 12,0 m3
